TRP4P3T8P6A

TRP4P3T8P6A

Product Image:

Product Plot:

Download Plot

View Outline Drawing

Product Description:

A triplexer processing a DC – 18 GHz input signal into 3 contiguous passbands with crossovers at 4.3 and 8.6 GHz, an additional low pass at 2 GHz, and very low losses. Connectors are 2.4mm (F) at input and (M) at outputs.

Input

DC – 18 GHz

Passbands

2 – 4.3 – 8.6 – 18 GHz

Insertion Loss

< 1.0 dB

Return Loss

> 12 dB

Typical Size of Painted Housing

55.8 x 31.6 x 10.4 mm
